Model: SCA70
Product title: In-Door Settable Current LED Driver – SC series; 60W; Linear
(part number: SC-AD-070W-1A40-A-AV-20-L)
Description:
Dimmable Multi-Power constant current LED Driver with 0-10V/1-10V dimming interface. Output current selectable with wide range of output voltage range. The AUX 12Vdc output to provide the drive power to other control module such as wireless module, sensor module.
Product Feature:
- Linear shape multi-Power constant current output LED Driver
- Active power factor control
- IP20 independent LED driver, for indoor use
- Nominal life 50,000hrs (at tc 65 °C with a failure rate <0.2% per 1,000hrs)
- Selectable output current by dip switch with 15 levels selection
- AUX 12V output for drive other control module.
- Dimming interface: 0-10V/1-10V
- Output current: 700mA, 750mA, 800mA, 850mA, 900mA, 950mA, 1000mA, 1050mA, 1100mA, 1150mA, 1200mA,1250mA, 1300mA, 1350mA, 1400mA
